Transformer Coil Winder Lathe Heavy Duty Automatic Coil Winding Machine

Introduction of automatic coil winding machine ZPX2500

Automatic coil winding machine ZPX2500 is a professional wire coil winder. The automatic coil winding machine adopts automatic wire laying and tension technologies, which is especially suitable for winding different shapes of coils. These coils can be used in transformers and other similar products. The automatic coil winding machine is provided with main winding motor, automatic wire laying unit, layer insulation unit, pneumatic system, PLC, and servo motors, etc. The automatic coil winding machine can wind the coil with maximum width 2500mm. With HMI and PLC, the automatic coil winding machine can be operated very easily.

Main components of automatic coil winding machine ZPX2500

1. Main frame

2. Winding unit

3. Automatic wire laying unit

4. Insulation decoiler

5. Electronic control system

6. Pneumatic system

Technical parameters of automatic coil winding machine ZPX2500

Typical standard specifications of automatic coil winding machine ZPX2500 are shown below, however the coil winding machine can also be manufactured as requested.

Fig 1: Automatic coil winding machine ZPX2500's full view

Fig 2: Automatic coil winding machine ZPX2500's side view
