Semi Automatic Motor Coil Winding Machine With Copper Wire

Description of motor coil winding machine MW350

Semi automatic motor coil winding machine MW350 is used for winding motor coil and other similar products. The motor coil winding machine is provided with strong main steel frame, flange to fix the mould for motor coil, foot pedal, counter, control board, winding motor, gear box and electrical cabinet etc. The motor coil winding machine features easy operation, high torque, and so on.

Main features of motor coil winding machine MW350

• Slow starting, at the beginning of the rotating, the winding speed is very slow
• Smooth running, during the machine running, it is very stable
• Big power motor with 1.5kw
• Easy operating, operating this winding machine is very easy and simple

Main parameters of motor coil winding machine MW350

Typical standard specifications of motor coil winding machine MW350 are shown below and the coil winding macihne can also be manufactured as requested.

Fig 1: Motor coil winding machine MW350's full view

Fig 2: Motor coil winding machine MW350's controller
