Automatic Cut To Length Automatic Core Cutting Machine Making Reactor Core


Description of automatic core cutting machine DHJ400

Automatic core cutting machine DHJ400 is a professional cutter, which can be used to cut silicon steel strip for making reactor cores. The automatic core cutting machine can cut the silicon steel with maximum width 400mm. The automatic core cutting machine can punch holes on the strip if needing. The servo motor is used to drive cutting and punching operation, which guarantees the accuracy of the operation. The cutter and shearing blade of the automatic core cutting machine adopts carbide cutter knife with HRC88 ~ 90 hardness, regrinding after more than 5 million cuts. With PLC control , it is very easy to operate the automatic core cutting machine through a touch screen.


Quick details of automatic core cutting machine DHJ400

• Cutting sheet thickness 0.23 ~ 0.35mm
• Cutting sheet width 25 ~ 400mm
• Cutting sheet length 10 ~ 9999mm
• Feeding speed 180m/min
• Total power 12.5kw
• One year warranty

Main components of automatic core cutting machine DHJ400

1.Dereeler for placing steel material
2.Main frame
3.Feeding sheet unit
4.Hole punching device
5.Shearing unit
6.Stacking table
7.Control system

Main parameters of automatic core cutting machine DHJ400

Typical standard specifications of automatic core cutting machine DHJ400 are shown below, however the automatic core cutting machine can also be manufactured as requested.

Fig 1: Automatic core cutting machine DHJ400's full view

Fig 2: Automatic core cutting machine DHJ400's stacking table
