PLC Control Transformer Foil Winding Machine 1200mm Width Copper Strip

PLC Control LV Transformer Foil Winding Machine Winding 1200mm Width Copper Strip

Description of transformer foil winding machine BRJ1200-2

Low voltage transformer foil winding machine BRJ1200-2 is a professional equipment to wind conductor foil coils to make dry type transformer coils and other similar products. The transformer foil winding machine is provided with big power main winding motor, foil decoilers, insulation decoilers, photoelectric sensor and cutter etc. The transformer foil winding machine can wind one or two layers of foil with maximum width 1200mm. With TIG welding unit, the transformer foil winding machine can weld conductor film with bus bar together. With one touch screen, it is very easy to operate the transformer foil winding machine.

Main components of transformer foil winding machine BRJ1200-2

Main frame,
Winding unit,
Foil decoiler,
Insulation decoiler,
End-fill strip feeder,
Cleaning system,
Cutting system,
Foil deburring system,
Edge alignment system,
Automatic welding unit,
Electronic control system,
Pneumatic system, etc.

Technical parameters of transformer foil winding machine BRJ1200-2

Typical standard specifications of transformer foil winding machine BRJ1200-2 are shown below, however, the transformer foil winding machine can also be manufactured as requested.

Max. Foil Width:	1,200mm
Max. Finished Coil OD:	Φ1,000mm
Min. Finished Coil ID:	Φ130mm
Finished Coil Shape:	oval, circle and rectangular, etc
Conductor Foil Material:	Copper or Aluminum
Foil Thickness Min. and Max. (Aluminum):	0.3 ~ 3.0 mm
Foil Thickness Min. and Max. (Copper):	0.2 ~ 2.0 mm
Conductor Foil Material OD.:	Φ1,000mm
Conductor Foil Material ID.:	Φ500mm
Conductor Decoiler Diameter:	Φ400 ~ 520mm
Winding Power:	15KW
Winding speed:	0 ~ 20 rpm
Welding Mode:	TIG
Cutting Mode:	Electric rolling shear
Insulation Decoiler Shaft:	Expandable (pneumatic open/close action)
End-fill Strip Feeder:	8 pcs
Edge Alignment System:	Photoelectric sensing automatic rectifying deviation
User Interface:	10inch (254mm) touch screen
Counting Range:	0 ~ 9999.9

FIG 1: Transfomer foil winding machine's side view

Fig 2: Transformer foil winding machine BRJ1200-2's back view
