Description of transformer coil winding machine GDY-5T

Transformer coil winding machine GDY-5T is a professional transformer coil winding equipment. This kind of transformer coil winding machine can be used to wind copper wire or aluminium coil to make wire coils. The transformer coil winding machine is provided with a digital counter, which makes the transformer coil winding machine be able to count the turns when winding. Moreover, the number of turns can be preset, after completing winding the preset number of turns, the machine will stop automatically. The transformer coil winding machine’s rotating speed can be adjusted through a potentiometer on the control board. Starting or stopping the transformer coil winding machine can be done through the foot pedal. The transformer coil winding machine features slow starting, smooth running, high torque, and so on.

Main components of transformer coil winding machine GDY-5T

o Main frame

o Square shaft

o Split tailstock

o Foot pedal

o Counter

o Control board

Main parameters of transformer coil winding machine GDY-5T

Typical standard specifications of transformer coil winding machine GDY-5T are shown below and the transformer coil winding machine can also be manufactured as requested.

Fig 1: Transformer coil winding machine GDY-3T's full view

Fig 2: Transformer coil winding machine GDY-3T's control panel
