Wire Winding Machine Electric Motor Coil Winding Machine

Description of motor coil winding machine MW1200

Motor coil winding machine MW1200 is a kind of special winder equipment. The motor coil winding machine can wind both copper wire and aluminium wire. These wound coils can be used in motors or other similar products. With an adjustable mold, the motor coil winding machine can wind different sizes of coils. The adjustable mold is with two movable blocks and the winding former can be mounted on thees two blocks. The distance between the two blocks can be adjusted and the adjustable range is from 150mm to 1200mm. The motor coil winding machine features easy operation and so on.

Quick details of motor coil winding machine MW1200

• Motor power 3kw
• Machine body height 1400mm
• Winding speed 0 ~ 80rpm
• Smooth running
• Adjustable blocks
• Simply structure

Main parameters of motor coil winding machine MW1200

Typical standard specifications of motor coil winding machine MW1200 are shown below, however, the motor coil winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW1200's full view

Fig 2: Motor coil winding machine MW1200's control board
